Specifications of DE2000 series
The following information is a summary of specifications of the DE2000 series.
• “Specifications of DE2000H (12 drives)” on page 6
• “Specifications of DE2000H (24 drives)” on page 8
Note: The following values can vary depending on your model and configuration.
Specifications of DE2000H (12 drives)
Specification DE2000H (12 drives)
Dimension
• Form factor: 2U
• Height: 85 mm (3.35 inches)
• Width: 448 mm (17.64 inches)
• Depth: 536 mm (21.10 inches)
Weight
28.78 kg (63.45 lb)
Processor
Two 64-bit 2-core, Broadwell DE 2.20 GHz processors
System memory 16 GB (8 GB per controller)
Supported drives
• 3.5-inch NL-SAS drives
• 2.5-inch SAS SSD/HDD drives in a 3.5-inch adapter tray
System Maximums and Limits
• Max. raw capacity: 576 TB
• Max. HDD drive count: 48
• Max. SSD drive count: 48
• Max. expansion shelf count: 3
• Max. volume count: 512
• Max. drives per disk pool: 48
• Max. disk pool volumes: 512
• Max. Vol size for a disk pool volume (TB): 857
• Max. disk pools: 20
• Max partitions: 128
• Max volumes per partition: 256
• Flash read cache (Min/Max): SSD SLC/MLC (400/5120 GB)
• Max destaging cache-to-flash size: 8 GB
Interfaces Available with the following interfaces:
• 16Gb Fibre Channel
• 12Gb SAS
• 10Gb iSCSI optical
• 10Gb iSCSI BaseT (RJ-45)
System clearance dimension The clearance needed for proper ventilation and heat dissipation is as follows:
• Front: 813 mm (32.02 inches)
• Rear: 610 mm (24.02 inches)
6 ThinkSystem DE Series Hardware Installation and Maintenance Guide for 2U Enclosures
