Lenovo ThinkSystem SR550 - Remove the System Board

Remove the system board
Use this information to remove the system board.
“Read the
installation
Guidelines” on
page 53
“Power off
the server
for this task”
on page 13
“ATTENTION:
Static Sensitive Device
Ground package before opening”
on page 56
Attention: Disconnect all power cords for this task.
Before removing the system board:
1. Remove the top cover. See “Remove the top cover” on page 56.
2. Record where the cables are connected to the system board; then, disconnect them.
Attention: Disengage all latches, cable clips, release tabs, or locks on cable connectors beforehand.
Failing to release them before removing the cables will damage the cable connectors on the system
board. Any damage to the cable connectors may require replacing the system board.
3. Remove any of the following components that are installed on the system board and put them in a safe,
static-protective place. See the related topics in this chapter.
• Air baffle
• System fans
• Processor and heat sink module (PHM)
Note: Do not disassemble the PHM.
• Riser assembly
• DIMMs
• LOM adapter
• TCM/TPM (for Chinese Mainland only)
• M.2 module
• PCIe adapter
• CMOS battery
4. Pull out the power supplies a little bit. Ensure that they are disconnected from the system board.
To remove the system board, complete the following steps:
Watch the procedure
A video of this procedure is available at
https://www.youtube.com/playlist?list=PLYV5R7hVcs-
C9jFjZnXQ6AmTXaIdX6_HJ
.
156
ThinkSystem SR550 Maintenance Manual
