Lenovo XClarity Energy Manager is a power and temperature management solution for data centers. You
can monitor and manage the power consumption and temperature of Converged, NeXtScale, System x,
and ThinkServer servers, and improve energy efficiency using Lenovo XClarity Energy Manager.
• Redundant networking connection
The Lenovo XClarity Controller provides failover capability to a redundant Ethernet connection with the
applicable application installed. If a problem occurs with the primary Ethernet connection, all Ethernet
traffic that is associated with the primary connection is automatically switched to the optional redundant
Ethernet connection. If the applicable device drivers are installed, this switching occurs without data loss
and without user intervention.
• Redundant cooling and optional power capabilities
The server supports a maximum of four 1100-watt (110V or 220V ac) or 1600-watt (220V ac) hot-swap
power supplies and six or twelve hot-swap fans, depending on the server configuration. The redundant
cooling by the fans in the server enables continued operation if a fan fails.
Note: You cannot mix power supply types in the server.
• ThinkSystem RAID support
The ThinkSystem RAID adapter provides hardware redundant array of independent disks (RAID) support
to create configurations. The standard RAID adapter provides RAID levels 0 and 1. An optional RAID
adapter is available for purchase.
Specifications
The following information is a summary of the features and specifications of the server. Depending on the
model, some features might not be available, or some specifications might not apply.
Table 1. Server Specifications
Specification
Description
Size
4U server
• Height: 175.8 mm (6.9 in.)
• Depth:
– EIA flange to rear: 800.0 mm (31.5 in.)
– Overall: 853.0 mm (33.6 in.)
• Width:
– Top cover: 447.0 mm (17.6 in.)
– EIA flange: 483.0 mm (19.0 in.)
Weight Approximately 32.6 kg (71.9 lbs.) to 58.7 kg (129.4 lbs.) depending on your
configuration.
Processor (depending on the
model)
Supports multi-core Intel Xeon processors, with integrated memory controller and
Ultra Path Interconnect (UPI)
• Two processors, minimum (expandable up to eight).
• Designed for the LGA 3647-0 socket
• Scalable up to 224 cores (with eight processors installed)
For a list of supported processors, see
http://www.lenovo.com/us/en/serverproven/
and the “Processor Options” section of the Lenovo ThinkSystem SR950 Product Guide
at http://lenovopress.com/LP0647
.
