Lenze 8400 HighLine C - Page 140

Mechanical installation
Standard devices in a power range of 30 ... 45 kW
Assembly without filter in "standard" technique
5
l
140
EDS84ASC552 EN 8.1
TopLine
8400GG108f
Fig. 5−43 Device dimensions
h b t h
1
h
2
t
1
t
2
g
1
g
2
g
3
[kW] [mm]
E84AVTCE3034xXx
30
450 250 265 520 636 252 291 8.5 16 18
E84AVTCE3734xXx
37
E84AVTCE4534xXx
45
E84AVTCE3034xBx
30
450 250 285 520 636 272 311 8.5 16 18
E84AVTCE3734xBx
37
E84AVTCE4534xBx
45
