Electrical installation
TopLine C control terminals
Axis bus
6
l
230
EDS84ASC552 EN 8.1
6.9.3 Axis bus
) Note!
This connection is not supported in versions below 8400 TopLine, SW version
02.00. This connection must not be wired in these lower versions.
X10
,
"
"
"
CAN-Ground
X10
CAN-Low
CAN-High
Sync/State
EDS84AVxxxx
AL
AH
AG
R
R
CA
O
N
AB
AS
AL
AH
AG
AS
120Ω
8400TLC002o 8400TLC009
Terminal data
Conductor cross−section Tightening torque
!
[mm
2
] [AWG] [Nm] [lb−in]
Flexible
0.2 ... 1.5
24 ... 16 − − −
With wire end ferrule
I/O axis bus
Labelling Feature Rated value
X10/AS I/O axis bus connection TTL level: 5 V
X10/AG GND, reference potential: I/O axis bus
Data transfer axis bus
Labelling Feature Rated value
X10/AH, AL Data transfer axis bus connection Acc. to CAN specification
Cable lengths: See CAN on board
Baud rate 500 kbps, constant
Terminating resistor 120 , switching via DIP switch
X10/AG GND, reference potential: Data transfer axis bus
