Lenze 8400 HighLine C

Electrical installation
TopLine C control terminals
Resolver connection
6
l
228
EDS84ASC552 EN 8.1
6.9 TopLine C control terminals
Devices of the TopLine C version have identical connections as described under "HighLine
C control terminals" (¶ 220). The additional control terminals of the TopLine C version are
described in the following.
6.9.1 Resolver connection
X7
X7
+Cos
-Cos
+Ref
-Ref
+Sin
-Sin
Vcc
-KTY
+KTY
1
2
3
4
5
6
7
8
9
KTY
TX
SSP94RESX7 b
Fig. 6−43 Wiring principle
Terminal data
Conductor cross−section Tightening torque
!
[mm
2
] [AWG] [Nm] [lb−in]
Flexible
0.2 ... 1.5
24 ... 16 − − −
With wire end ferrule
