Lenze 8400 HighLine C User Manual

Technical data
HighLine C control terminals
Analog inputs
4

81
EDS84ASC552 EN 10.0
4.7.2 Analog inputs
Labelling Feature Rated value
X3/A1U, A2U
Input
±10V
Input resistance >80k
Input voltage in case of open circuit Display ”0” (U < 0.2 V, absolute)
Sampling frequency 1kHz(1ms)
Accuracy  0.1 V
Electric strength of external voltage  15 V, permanent
A/D c onverter Resolution 10 bits + sign
Error 1 digit 0.1 % relating to the final value
X3/A1I, A2I Input
0 ... +20 mA
Parameterisable
4 ... +20 mA, fail-safe
Input resistance 215 
Input current in case of open circuit Display ”0” (I < 0.1 mA)
Sampling frequency 1kHz(1ms)
Accuracy  0.1 mA
Electric strength of external voltage  7 V, permanent
A/D c onverter 10 bit resolution
Error 1 digit 0.1 % relating to the final value
X3/GA GND, reference potential for analog signals
4.7.3 Analog outputs
Labelling Features Rated value
X3/O1U, O2U
Output voltage
0...10V
Output current 2mA
Capacitive load max 1 F
Voltage - 0 V Display ”0” (U < 0.1 V, absolute)
Output voltage at reset <0.5V
Accuracy 2 % relating to the final value
Short-circuit strength Unlimited period
Electric strength of external voltage Not guaranteed
X3/O1I, O2I
Output current
0...20mA
Parameterisable
4...20mA,fail-safe
Output voltage 0...10V
Current for output 0 mA I<0.1mAabs.
Output current in the case of reset <1mA
Accuracy  2 % relating to the final value
Short-circuit strength Unlimited period
External voltage protection Not guaranteed
X3/AR
Reference 10 V 10.5 V
Tolerance ±0.5 V
Capacitive load max 1 F
Short-circuit strength Unlimited period
Electric strength of external voltage Not guaranteed
Permissible current loading 10 mA
X3/GA GND, reference potential for analog signals
