Electrical installation
Important notes
Safety instructions for the installation according to U
L
or U
R
6
l
160
EDS84ASC552 EN 8.1
The values of the fuses used may be equal to or fall below the values in the following table:
Branch circuit protection
Fuse [A] Circuit breaker
Type
with mains
choke
without mains
choke
Type 5kA rms Type 50kA rms Rating
E84AVxxx2512 6 6
Schneider Electric:
Multi9 C60
Charact. C
Moeller:
FAZ−C
Charact. C
Siemens:
3RV1742
15 A
E84AVxxx3712 10 10 15 A
E84AVxxx5512 10 10 15 A
E84AVxxx7512 15 15 15 A
E84AVxxx1122 20 20 20 A
E84AVxxx1522 25 25 25 A
E84AVxxx2222 30 30 30 A
E84AVxxx3714 6 6 15 A
E84AVxxx5514 6 6 15 A
E84AVxxx7514 6 6 15 A
E84AVxxx1124 10 10 15 A
E84AVxxx1524 10 10 15 A
E84AVxxx2224 10 10 15 A
E84AVxxx3024xxS 15 15 15 A
E84AVxxx3024xx0 15 15 15 A
E84AVxxx4024 20 20 20 A
E84AVxxx5524 20 20 20 A
E84AVxxx7524 20 25
Siemens:
3RV1742
25 A
E84AVxxx1134 30 40 40 A
E84AVxxx1534 50 − 50 A
E84AVxxx1834 60 60
− −
−
E84AVxxx2234 60 − −
E84AVxxx3034 80 − − − −
E84AVxxx3734 100 − − − −
E84AVxxx4534 125 − − − −
J Warnings!
For CSA Certification drives are intended to be used with Chokes −
UL Recognized (XPTQ2/8, FOKY2/8) or CSA Certified (XPTQ2, FOKY2), File
Number E103521 or E198787, mounted on the line side of the devices.
The chokes are listed in chapter 4.2 Rated Data and chapter 11.2 Accessories.
