Lenze 8400 HighLine C

Accessories (overview)
Communication modules
11
l
276
EDS84ASC552 EN 8.1
11.7 Communication modules
The communication modules for the Inverter Drives 8400 serve to link the control system
and the Inverter Drives 8400 controllers. The table below contains an overview of the
available communication modules and their features.
Communication modules for Inverter Drives 8400
Feature PROFIBUS PROFINET EtherCAT POWERLINK INTERBUS
Type designation E84AYCPM E84AYCER E84AYCET E84AYCEC E84AYCIB
Communication profile PROFIBUS−DP PROFINET EtherCAT Ethernet
POWERLINK
INTERBUS
Node type Slave Slave Slave Slave Slave
Slot MCI MCI MCI MCI MCI
StateLine C     
HighLine C     
TopLine C     
Status display 5 LEDs 9 LEDs 9 LEDs 9 LEDs 5 LEDs
Address switch  − −  −
Connection Sub−D 2 x RJ45 2 x RJ45 2 x RJ45 2 x Sub−D
External voltage supply − 24 V
DC
24 V
DC
24 V
DC
24 V
DC
Bus electrically isolated     
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Communication manuals
Further information on the communication modules is provided in the
respective communication manuals.
The PDF files are provided on the Internet in the download area at Lenze website.
