1×counter/16×digital input
4
The modular system
4.23
L
4.23−3
EDSPM−TXXX−9.0−11/2009
Type
1×counter/16×digital input
Voltage supply DC 5 V / 100 mA (via backplane bus)
Connectable cable cross−section £ 1.5 mm
2
(³ AWG 16)
Digital inputs
Rated input voltage DC 24 V (DC 18 ... 28.8 V)
Number of inputs 16
Level LOW: DC 0 ... 5 V
HIGH: DC 15 ... 28.8 V
Input current 7 mA
Input resistance 3.3 kW
Delay time 3 ms
Delay − pulse input 100 ms
Counter
Number 1
Inputs 2
Max. frequency 100 kHz
Electrical isolation from the backplane bus Yes, via optocouplers
Communication
Input data 6 bytes
Output data 6 bytes
Parameter data 1 byte
Dimensions
Width 25.4 mm
Height 76.0 mm
Depth 76.0 mm
Weight 50 g
Order designation EPM−T430
Technical data
