Diagnostics
Diagnostic data
10
Networking via PROFIBUS−DP
10.6
10.6.2
L
10.6−3
EDSPM−TXXX−9.0−11/2009
The code−related diagnostic data contains information about the slot on which an
error has occurred.
l The code−related diagnostics are activated via the parameter setting.
Byte Assignment
Byte 1
Bit 5 ... 0 000010 Length of code−related diagnostic data
Bit 7, 6 01 Code for code−related diagnostics
Byte 2 Bit 7 ... 0
The corresponding bit is set to "1" if the following occurs on a slot
· the module is disconnected,
· a non−configured module is connected,
· the module cannot be accessed,
· the module reports a diagnostic alarm.
00000001 Module slot 1
00000010 Module slot 2
00000100 Module slot 3
00001000 Module slot 4
00010000 Module slot 5
00100000 Module slot 6
01000000 Module slot 7
10000000 Module slot 8
Byte 3 Bit 7 ... 0
00000001 Module slot 9
00000010 Module slot 10
... ...
10000000 Module slot 16
Byte 4 Bit 7 ... 0
00000001 Module slot 17
00000010 Module slot 18
... ...
10000000 Module slot 24
Byte 5 Bit 7 ... 0
00000001 Module slot 25
00000010 Module slot 26
... ...
10000000 Module slot 32
Code−related diagnostic data
