The following bytes with fixed assignment are available for parameter data:
Byte Assignment Lenze
setting
0 Activate / deactivate wire
breakage detection and
enabling/inhibiting diagnostic
alarm
1)
2)
Bit 0
Wire breakage detection for input E.0
00
h
0 Deactivated
12.3−6
1 activated
Bit 1
Wire breakage detection for input E.1
0 Deactivated
12.3−6
1 activated
Bits 2 ... 5
Reserved
Bit 6
0 Diagnostic alarm
inhibited
12.3−6
1 Diagnostic alarm
enabled
1
reserved Bits 0 ... 7 Reserved
2 Select signal function for
input E.0
Selection of signal function 12.3−18 3Bh
3 Select signal function for
input E.1
4 Select signal function for
output E.0
01
h
5 Select signal function for
output E.1
6 Select options for input E.0
Bits 0 ... 3
Conversion speed
3)
Resolution 00
h
7 Select options for input E.1
0000 15 conversions/s 16 Bit
00
h
0001 30 conversions/s 16 Bit
0010 60 conversions/s 15 Bit
0011 123 conversions/s 14 Bit
0100 168 conversions/s 12 Bit
0101 202 conversions/s 10 Bit
0110 3.7 conversions/s 16 Bit
0111 7.5 conversions/s 16 Bit
Bits 4 ... 7
Reserved
8...11 Reserved
1)
The wire breakage detection is used in the measuring range 4 ... 20 mA. If the wire breakage detection is
activated in byte 0 and the diagnostic alarm is enabled, a current reduction to below 0.8 mA is indicated.
2)
If the diagnostic alarm is enabled in byte 0, diagnostic data are transmitted to the master via the emergency
telegram in the event of an error.
3)
The conversion speeds given are valid for the operation of an analog input. When operating several inputs, divide
the corresponding conversation speed by the number of active inputs to detect the conversion speed per input.
Please note that the resolution is reduced with higher conversion speeds due to shorter integration times. The
data transfer format remains the same. Only the lower bits (LSBs) are not relevant anymore for the analog value.
