Parameterising analog modules
Parameter data
13
Parameter setting via PROFIBUS−DP
13.1
13.1.1
L
13.1−2
EDSPM−TXXX−9.0−11/2009
The following bytes with fixed assignment are available for parameter data:
Byte Assignment Lenze
setting
0 Enabling/inhibiting diagnostic
alarm
1)
Bits 0 ...
5 %
Reserved
00
h
Bit 6
0 Alarm inhibited
 12.3−6
1 Alarm enabled
Bit7
Reserved
1 Reserved
2 Selecting signal function for
input E.0
Selection of signal function  13.1−7
3 Selecting signal function for
input E.1
4 Selecting signal function for
input E.2
5 Selecting signal function for
input E.3
6 Select options for input E.0
1)
Bits 0 ...
3
Conversion speed
2)
Resolution 00
h
7 Select options for input E.1
1)
0000
0001
0010
0011
0100
0101
0110
0111
15 conversions/s
30 conversions/s
60 conversions/s
123 conversions/s
168 conversions/s
202 conversions/s
3.7 conversions/s
7.5 conversions/s
16 Bit
16 Bit
15 Bit
14 Bit
12 Bit
10 Bit
16 Bit
16 Bit
00
h
8 Select options for input E.2
1)
00
h
9 Select options for input E.3
1)
00
h
Bits 4 ...
5 %
Data selection
00 Deactivated
01 Use 2 of 3 values
10 Use 4 of 6 values
Bits 6 ...
7
Hysteresis
00 Deactivated
01 Hysteresis ±8
10
Hysteresis ±16
1)
The function is not available for the modules 4×analog input ±10V and 4×analog input ±20mA.
2)
The conversion speeds given are valid for the operation of an analog input. When operating several inputs, the
corresponding conversion speed must be divided by the number of active inputs to detect the conversion speed
per input.
Please note that due to shorter integration times the resolution is reduced at higher conversion speeds. The data
transfer format remains the same. Only the lower bits (LSBs) no longer are relevant for the analog value.
