Parameterising analog modules
Parameter data
13
Parameter setting via PROFIBUS−DP
13.1
13.1.1
L
13.1−4
EDSPM−TXXX−9.0−11/2009
l For the 4xanalog input/output module, up to 8 bytes of parameter data are
available. The following are defined via the parameter data
– The signal function for each input or output (current measurement, voltage
measurement, temperature measurement, or current signal output, voltage
signal output),
– The module error behavior,
– The conversion speed.
l The module can be parameterised with the configuration tool or via slot and
index.
– To set the parameters via slot and index, the function blocks SFB 52 (read)
and SFB 53 (write) are required.
Slot number Index Access Description
1 ... 32 00
h
R Read out diagnostic data record 0
W Write parameters to the module
01
h
R The corresponding diagnostic data record of the electronic module can be
read out via the index.
· Example:
– Index 01
h
: read out diagnostic data record 1
– Index 02
h
: read out diagnostic data record 2
F1
h
R Read out the module parameters
F2
h
R Read out the process image of the module
R = read
W = write
4xanalog input/output module
