Index table
15
Appendix
15.1
L
15.1−15
EDSPM−TXXX−9.0−11/2009
Index ImportantPossible settingsName
SelectionLenze
I4103
h
*
SSI control
0 {1} 255
SSI interface module
· Settings only apply to SSI mapping
standard 1 and 2 mode (I4104
h
= 1 and
2)
· Counter value is set under I4101
h
 12.5−1
Bit
1 Module 1 0 0 SSI control setpoint selection I/O0 (LSB)
Bit value 0: No selection via I/O.x
Bit value 1: Selection via I/O.x
2 Module 2 0 1 SSI control setpoint selection I/O1
3
Module 3 0 2 Reserved
... ... ... 3 SSI control output condition 0 SSI > setpoint Bit value 0: I/O.x is set 1, if counter value >
setpoint
Bit value 1: I/O.x is set 1, if counter value <
setpoint
8 Module 8 0 4 ... 7 Reserved
I4104
h
*
SSI mapping 0
Mapping for communication with Lenze
devices
 12.5−1
0 SSI mapping PLC Data exchange with PLC units using the
function blocks "L_IOSSIDataToIO" and
"L_IOSSIDataFromIO".
1 SSI mapping standard 1
Data exchange with 9300 controllers using
the function blocks CAN−IN/CAN−OUT
2 SSI mapping standard 2
I6000
h
Digital input 0 {1} 255
Display only
Digital input status
 8.10−3
1 Module 1
2 Module 2
... ...
64 Module 64
I6002
h
¿
Change polarity
digital input
0 {1} 255
Inverts digital input signals  12.2−1
1 Module 1 0
2 Module 2 0
... ... ...
64 Module 64 0
I6200
h
*
Digital output 0 {1} 255
· Digital output status
· The outputs can be set manually
(forcing):
– Depends on CAN status and I2360
h
 8.10−4
1 Module 1
2 Module 2
... ...
64 Module 64
I6202
h
¿
Change polarity
digital output
0 {1} 255
Inverts digital output signals  12.2−1
1 Module 1 0
2 Module 2 0
... ... ...
64 Module 64 0
I6206
h
¿
Error mode digital
output
0 {1} 255 Configures digital output monitoring
For the compact system, only index I6206
h
,
subindex 1 is available
 8.9−2
0 All digital outputs retain the last status output.
255 Response from I6207
h
In I6207
h
, the response can be configured
individually for each digital output
1 Module 1 0
2 Module 2 0
... ... ...
64 Module 64 0
