Index table
15
Appendix
15.1
L
15.1−16
EDSPM−TXXX−9.0−11/2009
Index ImportantPossible settingsName
SelectionLenze
I6207
h
¿
Error value digital
output
0
0 {1} 255
Configures the individual digital output
responses
For the compact system, only index I620
7h
,
subindex 1 is available
 8.9−2
8 bits of information
Bit value
0
Output switches to LOW
Bit value
1
Output retains last status output
1 Module 1 0
2 Module 2 0
... ... ...
64 Module 64 0
I6401
h
Analog input −32768 {1} 32767
Display only
Analog input status
Index is only available in the modular
system
 8.10−5
1 Channel 1
2 Channel 2
... ...
36 Channel 36
I6411
h
*
Analog output −32768 {1} 32767
· Analog output status
· The outputs can be set manually
(forcing):
– Depends on CAN status and I2360
h
· Index is only available in the modular
system
 8.10−5
1 Channel 1
2 Channel 2
... ...
36 Channel 36
I6421
h
¿
Trigger selection 0 {1} 255
Enables interrupt for analog inputs/outputs
Index is only available in the modular
system
1 Channel 1 0
2 Channel 2 0
... ... ...
36 Channel 36 0
I6423
h
¿
Global interrupt
enable
0 {1} 255
Global activation/deactivation of the
event−controlled process data transfer of
the analog input signals.
The setting in I6423
h
has a higher priority
than the settings in the TxPDOs.
· Lenze setting:
– System bus (CAN): I6423
h
= 255
– CANopen: I6423
h
= 0
· I6423
h
is only available for the modular
system.
0 Event−controlled process data transfer
deactivated
255 Event−controlled process data transfer activated
I6424
h
¿
Upper limit analog
input
00000000
h
{1} FFFFFFFF
h
Index is only available in the modular
system
1 Channel 1 0
2 Channel 2 0
... ... ...
36 Channel 36 0
I6425
h
¿
Lower limit analog
input
00000000
h
{1} FFFFFFFF
h
Index is only available in the modular
system
1 Channel 1 0
2 Channel 2 0
... ... ...
36 Channel 36 0
I6426
h
¿
Delta limit analog
input
00000000
h
{1} FFFFFFFF
h
Index is only available in the modular
system
1 Channel 1 0
2 Channel 2 0
... ... ...
36 Channel 36 0
