111
EDKVS9332X DE/EN/FR 8.0
EVS9321 ... EVS9326
9300std078
Position Description
Controller
Fixing rails for standard mounting
Cover for the motor connection
Shield connection support with fixing screws (2 items)
1 support for the shield sheet for the supply connections
1 support for the shield sheet for the motor cable
EMC shield sheet with fixing screws (2 items)
1 shield sheet for the supply connections
1 shield sheet for the motor cable and the feed cable for the motor temperature monitoring with PTC thermistor
or thermal contact (NC contact)
EMC shield sheet with fixing screws for shielded control cables
Cover for the supply connections
