Mechanical installation
Standard devices in the power range 15 ... 30 kW
Important notes
4
146
EDKVS9332X DE/EN/FR 8.0
4.2 Standard devices in the power range 15 ... 30 kW
4.2.1 Important notes
The accessory kit is located inside the controller.
Remove the cover of the drive controller
0
1
1. Remove the screws
2. Lift cover up and detach it
9300vec113
Mass of the devices
9300 Standard device "Cold plate" device
Type EVS93xx−Ex
[kg]
EVS93xx−Cx
[kg]
EVS9327−xx 13.5 9.5
EVS9328−xx 15.0 9.5
EVS9329−xx 15.0 ˘
