5.7 Standard devices in the power range 55 ... 75 kW
5.7.1 Important notes
To gain access to the power connections, remove the cover:
Remove the cover of the drive controller
0
1
1. Remove the screws
2. Lift cover up and detach it
9300vec113
Installation material required from the scope of supply:
Description Use Quantity
Cable ties 3.5 × 150 mm Strain relief/shield connection for motor cable 4
