Lenze EVS9321-Ex Mounting Instructions

Electrical installation
Wiring of the control connections
Device variant without "Safe torque off" function
5

200
EDKVS9332X DE/EN/FR 8.0
5.8.2 Device variant without "Safe torque off" function
Supply via internal voltage source
ƒ For the supply of the digital inputs (X5/E1 ... X5/E5) you have to set a freely
assignable digital output (e. g. X5/A1) permanently to HIGH level.
ƒ For the supply of the analog inputs (X6/1, X6/2 and X6/3, X6/4) you have to set a
freely assignable analog output (e. g. X6/63) permanently to HIGH level.
GND2 +24V
E5
A2 A3 A4 ST1
ST2
59
39
3k
47k
50mA
50mA
50mA
50mA
X5
28
E1 E2 E3 E4
3k
3k
3k
3k
3k
S1
A1
X3
X6
12
3
4
242R
1
2
3
4
5
6
100k
100k
100k
100k
3.3nF
GND1 GND1
7762
63
AIN1 AIN2
AOUTx
AOUT2
AOUT1
1
3
247
10k 10k
9300vec201
Fig. 5−26 Wiring of digital and analog inputs/outputs for internal voltage source
S1 Controller enable
NO contact or NC contact
Z
Load
Minimum wiring required for operation
Terminal assignment in the Lenze setting:  205
Supply via external voltage source
GND2 +24V
E5
A2 A3 A4 ST1
ST2
59
39
3k
47k
50mA
50mA
50mA
50mA
X5
28
E1 E2 E3 E4
3k
3k
3k
3k
3k
DC 24 V
(+18 V … +30 V)
S1
+
–
A1
X3
GND1 GND1
X6
12
3
4
7762
63
242R
1
2
3
4
5
6
100k
100k
100k
100k
3.3nF
AIN1 AIN2
AOUTx
AOUT2
AOUT1
1
3
247
10k 10k
9300std341
Fig. 5−27 Wiring of digital and analog inputs/outputs for external voltage source
S1 Controller enable
NO contact or NC contact
Z
Load
Minimum wiring required for operation
Terminal assignment in the Lenze setting:  205
