115
EDKVS9332X DE/EN/FR 8.0
Scope of supply
Description EVS9321 ...
EVS9326
EVS9327 ...
EVS9329
EVS9330 EVS9331
EVS9332
9300 servo controller 1 1 1 1
Mounting Instructions 1 1 1 1
Mounting material Standard mounting 142 147 152 157
"Cold Plate technique" 144 ˘ ˘ ˘
Installation material Power connections 163 173 182 190
Control connections 198
System bus (CAN) 209
Feedback system 210
Digital frequency input
Digital frequency output
214
Connections and interfaces
Position Description
L1, L2, L3, PE Mains connection 159
+UG, −UG DC supply 159
U, V, W, PE Motor connection 159
T1, T2 Connection of PTC thermistor or thermal contact (NC contact) of the motor 159
X1 AIF interface (automation interface)
Slot for communication module (e. g. XT EMZ9371BC keypad)
−
X3 Jumper for setting analog input signal at X6/1, X6/2 205
X4 System bus (CAN) connection 209
X5 Connection of digital inputs and outputs 198
X6 Connection of analog inputs and outputs 198
X7 Connection of resolver and KTY temperature sensor of the motor 210
X8 Connection of incremental encoder with TTL level or SinCos encoder and KTY temperature sensor of
the motor
210
X9 Connection of digital frequency input signal 214
X10 Connection of digital frequency output signal
X11 Connection of K
SR
relay output for "safe standstill" (for variants V004 and V104 only) 201
Status displays
Position LED red LED green Operating status
Off On Controller enabled
On On Mains is switched on and automatic start is inhibited
Off Blinking slowly Controller inhibited
Blinking quickly Off Undervoltage or overvoltage
Blinking slowly Off Active fault
