Lenze EVS9321-Ex Mounting Instructions

Technical data
Rated data
Operation at 400 V
3

136
EDKVS9332X DE/EN/FR 8.0
9300 Output currents
8 kHz
1)
16 kHz
1)
Rated current Maximum
current
2)
Standstill current Rated current Maximum
current
2)
Standstill current
Type I
r8
[A] I
M8
[A] I
08
[A] I
r16
[A] I
M16
[A] I
016
[A]
EVS9321−xx 1.5 2.25 2.3 1.1 1.65 1.7
EVS9322−xx 2.5 3.75 3.8 1.8 2.7 2.7
EVS9323−xx 3.9 5.85 5.9 2.9 4.35 4.4
EVS9324−xx 7.0 10.5 10.5 5.2 7.8 7.8
EVS9325−xx 13.0 19.5 19.5 9.7 14.6 14.6
EVS9326−xx 23.5 35.3 23.5 15.3 23.0 15.3
EVS9327−xx 32.0 48.0 32.0 20.8 31.2 20.8
EVS9328−xx 47.0 70.5 47.0 30.6 45.9 30.6
EVS9329−xx 59.0 88.5 52.0 38.0 57.0 33.0
EVS9330−xx 89.0 133.5 80.0 58.0 87.0 45.0
EVS9331−xx 110 165 110 70.0 105 70.0
EVS9332−xx 145 21.5 126 90.0 135 72.0
Bold print = Lenze setting
1)
Switching frequency of the inverter
2)
The currents apply to a periodic load change cycle with max. 1 minute overcurrent duration and 2 minutes base load
duration at max. 75 % I
r
