Lenze EVS9321-Ex Mounting Instructions

Technical data
Rated data
Operation at 480 V
3

138
EDKVS9332X DE/EN/FR 8.0
9300 Output currents
8 kHz
1)
16 kHz
1)
Rated current Maximum
current
2)
Standstill current Rated current Maximum
current
2)
Standstill current
Type I
r8
[A] I
M8
[A] I
08
[A] I
r16
[A] I
M16
[A] I
016
[A]
EVS9321−xx 1.5 2.25 2.3 1.1 1.65 1.7
EVS9322−xx 2.5 3.75 3.8 1.8 2.7 2.7
EVS9323−xx 3.9 5.85 5.9 2.9 4.35 4.4
EVS9324−xx 7.0 10.5 10.5 5.2 7.8 7.8
EVS9325−xx 13.0 19.5 19.5 9.7 14.6 14.6
EVS9326−xx 22.3 33.5 22.3 14.5 21.8 14.5
EVS9327−xx 30.4 45.6 30.4 19.2 28.8 19.2
EVS9328−xx 44.7 67.1 44.7 28.2 42.3 28.2
EVS9329−xx 56.0 84.0 49.0 35.0 52.5 25.0
EVS9330−xx 84.0 126 72.0 55.0 82.5 36.0
EVS9331−xx 105 157.5 105 65.0 97.5 58.0
EVS9332−xx 125 187.5 111 80.0 120 58.0
Bold print = Lenze setting
1)
Switching frequency of the inverter
2)
The currents apply to a periodic load change cycle with max. 1 minute overcurrent duration and 2 minutes base load
duration at max. 75 % I
r
