7 Fieldbus
Profibus quick start
102 Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016
The default setting for the Lenze control word (NetWordIN1) and Lenze status word (NetWordOUT1) are as
follow (SW 02.01):
Lenze control word (NetWordIN1)
Lenze status word (NetWordOUT1)
Bits
Function
Bits
Function
0
Not connected
0
Ready for operation
1
Not connected
1
Not connected
2
Quick Stop
2
Inverter enable
3
Not connected
3
Fault
4
Run forward (CW)
4
Not connected
5
Preset bit0 selection
5
Quick stop active
6
Preset bit1 selection
6
Running
7
Reset Fault
7
Device warning
8
Not connected
8
Not connected
9
DC brake
9
Not connected
10
Not connected
10
Setpoint speed reached
11
Not connected
11
At current limit
12
Invert rotation
12
Actual speed = 0
13
Not connected
13
Invert rotation
14
Not connected
14
Holding brake release
15
Not connected
15
Safe Torque Off
5. For network control the following setup needs to be done:
- For network control the P400:37 (0x2631:37) “Network enable” need to be set.
- Set P201:1 (0x2860:1) “Default frequency setpoint” to the network
6. Controlling the inverter
- With the default IO-setting DI1 need to be asserted (Run/Stop)
- Set “Network frequency setpoint 0.01Hz”, (Example 1234 = 12.34 Hz)
- Set Bit 4 of “Lenze control word (NetWordIN1)” to start the drive
i
Per default the watchdog timeout response for the communication is set to fault (P515:1, 0x2859:1).
