Lenze i510 - Device Utilization (Ixt); Error Code; Timer; Counter

6 Function & parameter description
Group 1 – Diagnostics
Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016 47
P126:3
0x282A:3
Cause of stop
i510
i550
R
Bit # description:
0: Flexible I/O: Run/Stop
1: Flexible I/O: Run CW
2: Flexible I/O: Run CCW
3: Flexible I/O: Jog CW
4: Flexible I/O: Jog CCW
5: Network
6: Keypad
7: Control mode transition
15: Waiting for start
Cause of stop (Bit coded)
P126:5
0x282A:5
CiA402 state machine
i510
i550
R
0: Initial
2: Not Ready to Switch On
3: Switch On Disabled
4: Ready to Switch On
5: Switched on
6: Operation enable
7: Disable Operation
8: Shut Down
9: Quick stop active
10: Fault reaction active
11: Fault
Actual state of inverter
6.3.14 Device utilization (ixt)
P135:4
0x2D40:4
Device utilisation (i*t)
i510
i550
R
-- ... [Actual value] ... -- %
Actual inverter utilization
P135:5
0x2D40:5
Device utilisation (i*t): Error response
i510
i550
R/W
2: Trouble
3: Error
Configuration of ixt error response
6.3.15 Error code
P150:0
0x603F:0
Error code
i510
i550
R
-- ... [Actual value] ... --
Actual pending error code.
See chapter "Troubleshooting" for code explanation
6.3.16 Timer / Counter
On the keypad timers are displayed in the following format:
Days (d), Hours (h), Minutes (m), Seconds (s) (Example: 05d15h13m12s)
P151:1
0x2D81:1
Operating time
i510
i550
R
-- ... [Actual value] ... -- s
Total operating time of inverter (Inverter released)
P151:2
0x2D81:2
Power-on time
i510
i550
R
-- ... [Actual value] ... -- s
Total time that inverter was powered on
P151:3
0x2D81:3
Control unit operating time
i510
i550
R
-- ... [Actual value] ... -- ns
Total time that control unit was powered on. It includes the time where
the control section is powered by USB adapter.
