6 Function & parameter description
Group 1 – Diagnostics
46 Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016
3: PID influence shown
4: Setpoint = actual value
5: Sleepmode active
6.3.11 Motor protection i2xt
P123:0
0x2D4F:0
Motor utilisation (i²*t)
i510
i550
R
-- ... [Actual value] ... -- %
Actual thermal load of the motor (I2xt)
6.3.12 Control / Setpoint Source
P125:1
0x282B:1
Active control source
i510
i550
R
-- ... [Actual value] ... --
Actual active control source
P125:2
0x282B:2
Active setpoint source
i510
i550
R
-- ... [Actual value] ... --
Actual active setpoint source
P125:3
0x282B:3
LCD icon states
i510
i550
R
-- ... [Actual value] ... --
Actual status of LCD (Bit coded)
P125:4
0x282B:4
Active drive mode
i510
i550
R
-- ... [Actual value] ... --
Actual drive mode
P125:5
0x282B:5
Actual control register
i510
i550
R
-- ... [Actual value] ... --
Network Mode:
Last active control register. Parameter Index is shown as hex code:
Format: 0xiiiiss00 (iiii = Index hexadezimal, ss = Subindex hexadezimal)
Example: 0x400C0100 --> 0x400C:01
P125:6
0x282B:6
Actual setpoint register
i510
i550
R
-- ... [Actual value] ... --
Network Mode:
Last active setpoint register. Parameter Index is shown as hex code:
Format: 0xiiiiss00 (iiii = Index hexadezimal, ss = Subindex hexadezimal)
Example: 0x400B0300 --> 0x400B:03
6.3.13 Inverter status
P126:1
0x282A:1
Cause of disable
i510
i550
R
Bit # description:
0: Flexible I/O: Inhibit
1: Network inhibit
2: Axis inhibit
6: DC bus voltage
7: Drive not ready
9: Motor parameter ident
10: Auto brake
12: CiA 402 disabled
13: CIA402 Quick stop inhibit
14: STO inhibit
15: CiA402 mode disabled
Cause of controller stop (Bit coded)
P126:2
0x282A:2
Cause of quick stop
i510
i550
R
Bit # description:
0: Flexible I/O: configuration
1: Network
2: Axis command
Cause of quick stop (Bit coded)
