Lenze i510 - NETword Configuration

8 Drive Profile (Fieldbus)
NETword Configuration
112 Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016
8.4 NETword Configuration
Instead of using the predefined command and status word there are general NETWords can be configured.
i
Depending on the fieldbus the mapping can be done in the Slave (inverter) or in the Master (PLC).
Note: If the mapping is done in the Master (Example: PROFIBUS) the mapping in the Slave is overwritten!
Master  Inverter (NETWordIn)
 NETWordIn1: Function trigger bit
Value: 0x4008:1 (P590:1)
Configuration: 0x400E:1 (P505:1-16)
 NETWordIn2: Switch digital outputs/relay
Value: 0x4008:2 (P590:2)
Configuration: 0x2643:1-3 (P420:1-3)
 NETWordIn3: Source for AO1/AO2
Value: 0x4008:3 (P590:3)
Configuration AO1: 0x2639:2 (P440:2)
Configuration AO1: 0x263A:2 (P441:2)
 NETWordIn4: Source for AO1/AO2
Value: 0x4008:4 (P590:4)
Configuration AO1: 0x2639:2 (P440:2)
Configuration AO1: 0x263A:2 (P441:2)
Inverter  Master (NETWordOut)
 NETWordOut1: Drive Status bits
Value: 0x400A:1 (P591:1)
Configuration: 0x2635:10-25 (P420:10-25)
 NETWordOut2: Switched by Sequencer
Value: 0x400A:2 (P591:2)
Configuration: Sequencer parameter
