6 Function & parameter description
Group 3 – Motor control
58 Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016
Functions:
Index
Display
Code
VFC open loop [6]
SLVC [4]
Servo control ASM [2]*
6.5.8 Switching frequency
0x2939:0
P305:0
X
X
X
6.5.2 V/f: Curve setting
0x2B00:0
0x2B01:X
P302:0
P303:X
X
6.5.3 V/f: Slip compensation
0x2B09:X
P315:X
X
6.5.4 V/f: Frequency boost
0x2B12:X
P316:X
X
6.5.11 Skip frequency
0x291F:X
P317:X
(X)
X
X
6.5.5 V/f: Oscillation damping
0x2B0A:X
P318:X
(X)
6.5.6 V/f: Override point of field weakening
0x2B0C:X
P319:X
(X)
6.5.12 Motor parameter
0x2C01:X
0x6075:0
P320:X
P323:0
(X)
X
X
6.5.13 Speed limitation
0x6080:0
P322:0
(X)
X
X
6.5.14 Current limitation
0x6073:0
P324:0
(X)
X
X
0
Torque limitation
0x6076:0
0x6072:0
P325:0
P326:0
X
X
(X) Optional
P300:0
0x2C00:0
Motor control mode
i510
i550
R/W
2: Servo Control ASM (*)
4: Sensorless vector control
6: VFC open loop
Selection of the motor control mode
P301:0
0x6060:0
Modes of operation
i510
i550
R/W
-2: MS-Velocity mode
0: Mode no change/assigned
2: Velocity mode (vl)
Selection of the operation mode of the inverter
-2: MS-Velocity mode: (Manufacturer specific velocity mode)
Speed controlled motor with optional PID (Normal operating mode)
0: Mode no change/assigned
No operation mode selected. Drive disabled.
2: Velocity mode (vl):
CiA402 velocity mode. Control word 0x6040 is following CiA402 standard
