6 Function & parameter description
Group 4 – I/O setup
70 Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016
P400:1
0x2631:1
Inverter enable
i510
i550
R/W
0: Not connected
1: Constant TRUE
11: Digital input 1
12: Digital input 2
13: Digital input 3
14: Digital input 4
15: Digital input 5
16: Digital input 6 (*)
17: Digital input 7 (*)
50: Running
51: Ready to run
53: Stop active
54: Quick stop active
58: Device warning
59: Device fault active
60: Heatsink temp. warning
69: Rotation inverted
70: Frequency thld exceeded
71: Actual speed = 0
78: Current thld exceeded
79: Maximum torque
80: Follower signal loss
81: Error analog input 1
82: Error analog input 2
83: Loss of load
104: Local control active
105: Remote control active
106: Manual setpoint active
107: Automatic setpoint active
State:
TRUE enables the inverter.
FALSE inhibits the inverter and the motor will cost stop.
Note:
Signal must have the state TRUE (by Input or setting) to be able to start
the motor
P400:2
0x2631:2
Run/Stop
i510
i550
R/W
11:Digital input 1
(Reference see P400:1)
Inverter Run/Stop signal
State:
TRUE will make the inverter ready to run
FALSE will stop the motor according to the defined stop method
Note:
Set 01 TRUE to disable the function
Signal must have the state TRUE (by Input or setting) to be able to start
the motor
P400:3
0x2631:3
Quick stop
i510
i550
R/W
0:Not connected
(Reference see P400:1)
The quick stop function works as pause or zero speed function. If the
quick stop is applied the motor will ramp down with the defined QSP
ramp.
Note:
0: FALSE disables this functionality
P400:4
0x2631:4
Reset fault
i510
i550
R/W
12:Digital input 2
(Reference see P400:1)
Trigger for fault reset
FALSE->TRUE transition the faults will be reset.
