6 Function & parameter description
Group 4 – I/O setup
72 Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016
P400:10
0x2631:10
Jog forward (CW)
i510
i550
R/W
0:Not connected
(Reference see P400:1)
JOG Forward with preset frequency 5
State:
TRUE will start the motor forward with preset frequency 5
FALSE will stop the motor
If JOG forward and JOG reverse are applied at the same time the motor
will stop and the JOG has to be retriggered!
WARNING:
The JOG functions have priority over Stop commands. If the inverter is
currently JOGGING, pressing the STOP key on the keypad or triggering
STOP command will NOT stop the motor!
P400:11
0x2631:11
Jog reverse (CCW)
i510
i550
R/W
0:Not connected
(Reference see P400:1)
JOG Forward with preset frequency 6
State:
TRUE will start the motor reverse with preset frequency 6
FALSE will stop the motor
If JOG forward and JOG reverse are applied at the same time the motor
will stop and the JOG has to be retriggered!
WARNING:
The JOG functions have priority over Stop commands. If the inverter is
currently JOGGING, pressing the STOP key on the keypad or triggering
STOP command will NOT stop the motor!
P400:12
0x2631:12
Keypad control
i510
i550
R/W
0:Not connected
(Reference see P400:1)
Keypad Selection for Start/Stop command
State:
TRUE: Start and Stop commands coming from the keypad
FALSE: Start and Stop commands are defined by the connection list
P400:13
0x2631:13
Invert rotation
i510
i550
R/W
13:Digital input 3
(Reference see P400:1)
Rotation inversion signal
State:
TRUE: target reference setpoint is inverted (i.e. times -1)
FALSE: the target reference setpoint in not inverted
