6 Function & parameter description
Group 4 I/O setup
Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016 77
50: Running
51: Ready for operation
52: Inverter enable
53: Stop active
54: Quick stop active
55: Safe Torque Off
56: Fault
57: Fault interlocking
58: Device warning
59: Device fault active
60: Heatsink temp. warn. active
65: PTC fault
66: Flying restart
67: DC brake active
69: Inverse rotation
70: Frequency thld exceeded
71: Actual speed = 0
72: Setpoint speed reached
73: PID feedback = setpoint
74: Sleep mode on
75: Minimum alarm
76: Maximum alarm
77: Minimum/Maximum alarm
78: At current limit
79: At torque limit
80: Follower signal loss
81: Error analog input 1
82: Error analog input 2
83: Loss of load
104: Local control active
105: Remote control active
106: Manual setpoint active
107: Automatic setpoint active
108: Parameter set 1 active
109: Parameter set 2 active
110: Parameter set 3 active
111: Parameter set 4 active
112: Parmeter set load OK
113: Parameter set load fail
114: Network control
115: Holding brake release
(P412:0)
71: TRUE when the output frequency is zero +/- 0.01Hz
72: TRUE when the inverter reaches the commanded setpoint and set-
point <> 0 Hz
73: TRUE when the PID feedback is equal to the programmed setpoint
+/- 2%
74: TRUE when in Sleep mode
75: TRUE when a minimum alarm is triggered (reference to P608:1)
76: TRUE when a maximum alarm is triggered (reference to P608:2)
77: TRUE when no minimum/maximum alarm is active. (reference to
P608:1 & P608:2)
78: TRUE when the actual motor current has exceeded the level in
P324:0.
79: TRUE when the actual torque has exceeded the level in P326:0,
0x60E0:0 or 0x60E1:0.
80: TRUE when AI1 / AI2 are configured for 4…20 mA, the setpoint
source is active and the signal falls below 2 mA.
81: TRUE when loss of the analog input 1 has been detected. P430:8-10
82: TRUE when loss of the analog input 2 has been detected. P431:8-10
83: TRUE when no load is detected
104: TRUE when local (LOC) mode is active (local keypad START control)
105: TRUE when remote (REM) mode is active (all control sources
EXCEPT keypad control)
106: TRUE when manual (MAN) mode is active (Keypad setpoint control)
107: TRUE when automatic (AUTO) mode is active (All setpoint sources
other than Keypad)
108: TRUE when parameter set #1 is loaded and active.
109: TRUE when parameter set #1 is loaded and active.
110: TRUE when parameter set #1 is loaded and active.
111: TRUE when parameter set #1 is loaded and active.
112: TRUE after any parameter set 1…4 change-over has completed
without error.
113: TRUE when any parameter set load fails.
114: TRUE when on AC Drive control word (P592:1) Bit 5 = TRUE (specifi-
cally for AC Drive profile)
115: TRUE when brake release signal is TRUE (either by auto trigger or
manual trigger).
P420:2
0x2634:2
Digital output 1
i510
i550
R/W
115:Holding brake release
(Reference see P420:1)
Function of Digital Output 1
(Reference list see P420:1)
P420:3
0x2634:3
Digital output 2 (*)
i550
R/W
56:Fault
(Reference see P420:1)
Function of Digital Output 2
(Reference list see P420:1)
Note: Only with Application IO
P421:1
0x2635:1
Relay
i510
i550
R/W
0: Not inverted
1: Inverted
Inversion of Relay Output
