6 Function & parameter description
Group 4 – I/O setup
Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016 79
P430:2
0x2636:2
Analog input 1: Min value [Hz]
i510
i550
R/W
-1000.0 ... [0.0] ... 1000.0 Hz
Frequency scaling of the analog input
Represents the minimum of the analog input value
P430:3
0x2636:3
Analog input 1: Max value [Hz]
i510
i550
R/W
-1000.0 ... [50.0] ... 1000.0 Hz
Frequency scaling of the analog input
Represents the maximum of the analog input value
P430:4
0x2636:4
Analog input 1: Min value [Punit/%]
i510
i550
R/W
-300.00 ... [0.00] ... 300.00 PUnit/%
PID/Torque scaling of the analog input
Represents the minimum of the analog input value
P430:5
0x2636:5
Analog input 1: Max value [Punit/%]
i510
i550
R/W
-300.00 ... [100.00] ... 300.00 PUnit/%
PID/Torque scaling of the analog input
Represents the maximum of the analog input value
P430:6
0x2636:6
Analog input 1: Filter time
i510
i550
R/W
0 ... [10] ... 10000 ms
Analog input filter time constant
P430:7
0x2636:7
Analog input 1: Deadband
i510
i550
R/W
0.0 ... [0.0] ... 100.0 %
Configuration of the deadband such that any input value below this per-
centage will be treated as 0Hz. (In % of Max Input Value)
Example: Deadband 10% of 50Hz:
-10V … 10V Deadband -5Hz … 5 Hz
0 … 10V Deadband 0Hz … 5 Hz
P430:8
0x2636:8
Analog input 1: Monitoring level
i510
i550
R/W
-100.0 ... [0.0] ... 100.0 %
Monitoring condition of the analog input
P430:9
0x2636:9
Analog input 1: Monitoring action
i510
i550
R/W
0: Below level 1
1: Above level 1
Monitoring condition of the analog input
P430:10
0x2636:10
Analog input 1: Error response
i510
i550
R/W
3:Fault
(Reference see P310:1)
Fault reaction of the analog input monitoring.
P431:1
0x2637:1
AI2 configuration
i510
i550
R/W
0: 0...10VDC
1: 0...5VDC
2: 2...10VDC
3: -10...+10VDC (*)
4: 4...20mA (*)
5: 0...20mA (*)
Configuration of analog input signal 2
Note: On i510 only unipolar voltage input available.
P431:2
0x2637:2
Analog input 2: Min value [Hz]
i510
i550
R/W
-1000.0 ... [0.0] ... 1000.0 Hz
Frequency scaling of the analog input
Represents the minimum of the analog input value
P431:3
0x2637:3
Analog input 2: Max value [Hz]
i510
i550
R/W
-1000.0 ... [50.0] ... 1000.0 Hz
Frequency scaling of the analog input
Represents the maximum of the analog input value
P431:4
0x2637:4
Analog input 2: Min value [Punit/%]
i510
i550
R/W
-300.00 ... [0.00] ... 300.00 PUnit/%
PID/Torque scaling of the analog input
Represents the minimum of the analog input value
P431:5
0x2637:5
Analog input 2: Max value [Punit/%]
i510
i550
R/W
-300.00 ... [100.00] ... 300.00 PUnit/%
PID/Torque scaling of the analog input
Represents the maximum of the analog input value
P431:6
0x2637:6
Analog input 2: Filter time
i510
i550
R/W
0 ... [10] ... 10000 ms
Analog input filter time constant
