7 Fieldbus
CANopen quick start
98 Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016
Default setting of NetWordIN1 / NetWordOUT1 (SW 02.01)
Lenze control word (NetWordIN1)
Lenze status word (NetWordOUT1)
Bits
Function
Bits
Function
0
Not connected
0
Ready for operation
1
Not connected
1
Not connected
2
Quick Stop
2
Inverter enable
3
Not connected
3
Fault
4
Run forward (CW)
4
Not connected
5
Preset bit0 selection
5
Quick stop active
6
Preset bit1 selection
6
Running
7
Reset Fault
7
Device warning
8
Not connected
8
Not connected
9
DC brake
9
Not connected
10
Not connected
10
Setpoint speed reached
11
Not connected
11
At current limit
12
Invert rotation
12
Actual speed = 0
13
Not connected
13
Invert rotation
14
Not connected
14
Holding brake release
15
Not connected
15
Safe Torque Off
