Leuze BPS 8 - Binary Protocol 6: BPS 8 SM 10 x-10

Protocols for position value output
Leuze electronic BPS 8 109
TNT 35/7-24V
9.5 Binary protocol 6 – BPS 8 SM 10x-10
With the BPS Configuration Tool, the user can individually adapt the binary protocols 1
and 6 to the specific requirements of the application. The binary protocols 2, 3 and 4, on the
other hand, have a fixed structure and cannot be modified.
9.5.1 Data format
Table 9.5: BPS 8 SM 10x-10 data format
9.5.2 Request telegram to the BPS 8 SM 10x-10
The request telegram consists of two bytes.
Request telegram structure
Description
Data format BPS 8 SM 10x-10
Baud rate 115.2 kBit/s
Number of data bits 8
Number of start bits 1
Number of stop bits 1
Parity None
Addressing None
Operating mode RS 232 full duplex
Handshake None
Byte no. Designation Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Request byte 0000ONOFF0DIAG
1 XOR combination Exclusive OR combination of byte 0 with 00
h
(repetition of the request byte)
Byte Bit Name Function Description
0
0
DIAG Request
diagnostic information
1 = Request diagnostic data
0 = Do not request diagnostic data
1 – None Without function, bit permanently set to 0
2
OFF Deactivate measurement
operation
1 = Deactivate measurement operation and cyclical measurement
value output
0 = No function
3
ON Activate measurement opera-
tion
1 = Activate measurement operation and cyclical measurement
value output
0 = No function
4…7 – None Without function, bit permanently set to 0
10XOR XOR combination Exclusive OR combination of byte 0 with 00
h
