Mounting and installation
Leuze electronic BPS 8 44
TNT 35/7-24V
6.2.2 BT 8-0 mounting device
The BT 8-0 mounting device is available to you for the clamp-mounting of the BPS 8 to the
dovetail on the rear of the device and the bottom of the device. It is intended for fastening at
system via two M4 screws. For order guide, please refer to Chapter 12.6 on Page 118.
Figure 6.10: BT 8-0 mounting device
NOTE
The angles of inclination required for device arrangement are not integrated with this
mounting device, in contrast with the BT 8-01.
