Configuration / device parameters
Leuze electronic BPS 8 67
TNT 35/7-24V
Setting the device-specific interface values
This sets the connection (interface) from the PC to the device and not the interface of the
device. For service interface operation, the settings here do not need to be edited.
If the connected device is not operated via the service protocol:
Use the left mouse button to select the device to be edited.
Right click and select Communication. In the Communication properties window that
opens, carry out the respective changes.
If the settings were changed, the Leuze standard parameters can be reselected by clicking
on the button.
MA 8-01/MA 8-02 connection unit
The MA 8-01/MA 8-02 connection unit is not relevant for the configuration and is thus not
explicitly supported in the BPS Configuration Tool.
8.2.3 Setting the parameters
You now have commissioned the BPS 8 and are ready to configure it. Using the parameter
options made available by the BPS 8, you can configure the BPS 8 to suit your individual
area of application. For instructions regarding the various setting options, refer to the online
help or to Chapter 8.5, Page 71.
The various parameter sets are explained briefly in Chapter 8.4, to understand what is
happening during parameter setting. The setting of the parameters then takes place in the
service operating mode, which is described in the following chapter.
