Protocols for position value output
Leuze electronic BPS 8 91
TNT 35/7-24V
9.2 Binary protocol 2 – BPS 8 SM 10x-02
With the BPS Configuration Tool, the user can individually adapt the binary protocols 1
and 6 to the specific requirements of the application. The binary protocols 2, 3 and 4, on the
other hand, have a fixed structure and cannot be modified.
9.2.1 Data format
Table 9.2: BPS 8 SM 10x-02 data format
9.2.2 Request telegram to the BPS 8 SM 10x-02
The request telegram consists of one byte.
Request telegram structure
Description
A0 and A1 are the address bits. If several BPS 8 operate in an RS485 network, an address
configuration is required. Every BPS 8 is supplied with the Standard address 0. The
Data format BPS 8 SM 10x-02
Baud rate 62.5 kBit/s
Number of data bits 9
Number of start bits 1
Number of stop bits 1
Parity None
Addressing 0 … 3
Operating mode RS232 half duplex
Handshake None
Byte no. Designation Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Request byte 1011S2S1S0A1A0
Byte Bit Name Function Description
0
0
A0 Address A1A0 in
RS 485 network
00 = Address 0
01 = Address 1
1
A1 10 = Address 2
11 = Address 3
2
S0 Coded data request through
the 3 bits S2, S1, S0
Coded request
S2 S1 S0 Meaning
3
S1 0 0 0 Request position data
0 0 1 Request marker data
4
S2 0 1 0 Request diagnostic data
1 0 0 Request one-time position data transfer
5 – None Without function, bit permanently set to 1
6 – None Without function, bit permanently set to 1
7 – None Without function, bit permanently set to 0
8 – None Without function, bit permanently set to 1
