Leuze BPS 8 - Reading Field Curves

Technical data of BPS 8
Leuze electronic BPS 8 15
TNT 35/7-24V
3.3 Reading field curves
BPS 8 SM 102 with front beam exit
Figure 3.3: Reading field curve BPS 8 SM 102 with front beam exit
BPS 8 SM 100 with lateral beam exit
Figure 3.4: Reading field curve BPS 8 SM 100 with lateral beam exit
-70
-60
-50
-40
-30
-20
-10
0
10
20
30
40
50
60
70
0 1020304050607080 90 100 110 120 130 140 150 160
170
Reading distance [mm]
Reading field width [mm]
Working range
BPS 8 SM 102
-70
-60
-50
-40
-30
-20
-10
0
10
20
30
40
50
60
70
0 102030405060 70 80 90 100 110 120 130 140 150 160
170
Reading distance [mm]
Reading field width [mm]
Working range
BPS 8 SM 100
