Configuration / device parameters
Leuze electronic BPS 8 74
TNT 35/7-24V
Maximum position value which can be represented
The binary protocols 1 to 6 convey the position value with a different number of data bits.
The number of data bits and the selected resolution determine the maximum position value
that can be represented.
Integration depth parameter
The integration depth parameter is used to specify the number of raw position data which is
used for integration in order to determine the position value.
In order to obtain more exact measurement data while in the static state or for very slow
travel speeds, the integration depth can be increased here. If, however, a high integration
depth is used for high speeds, the contouring error is increased. With respect to contouring
errors and exact measurement data, very good results have been obtained using 8 integra-
tion steps. Using 8 integration steps, the integration time is 26.4ms.
Maximum position value which can be represented with a resolution of
1mm (default) 0.1mm 0.01mm 0.001mm
Binary protocol 1, 4, 6
(32 data bits)
10,000,000
mm
1)
1) The maximum position value that can be presented is limited by the maximum length of
the bar code tape.
10,000,000mm
1)
10,000,000mm
1)
4,294,967mm
Binary protocol 2
(24 data bits)
10,000,000mm
1)
1,677,721mm 167,772mm 16,777mm
Binary protocol 3
(21 data bits)
2,097,152mm 209,715mm 20,971mm 2,097mm
Parameter Description Value range Default Unit CR
Integration
time
Number of consecutive scans
which are to be used for position
determination.
4…32 8
Integra-
tion
steps
–
Integration depth Integration time [ms]
4 13.2
5 16.5
6 19.8
7 23.1
8 (default) 26.4
9 29.7
10 33.0
::
29 95.7
30 99.0
31 102.3
32 105.6
