Configuration / device parameters
Leuze electronic BPS 8 76
TNT 35/7-24V
Scaling factor parameter
The scaling function is used to convert the tape values to any unit of measurement. To do
this, the tape value is multiplied by the scaling factor.
This parameter affects the Offset value. The Preset value parameter is not influenced by the
scaling.
Offset value parameter
This function adds an offset value to the tape value.
If the Preset parameter is activated and, as a result, a new value assigned to the tape value,
the Offset function no longer affects the position value. The offset is not reactivated until the
preset function is canceled. The offset value is entered in mm. When entering the offset
value, the scaling factor parameter must be taken into account.
Min./max. measurement length parameter
With this parameter, a working limit on the bar code tape can be defined. The BPS 8 outputs
position values within these minimum and maximum limits. Outside of this limit, a position
value of zero is output.
The switching output can be used to indicate that the measured value is outside of the
measurement range. To enable this function, the "outside measurement range" or "inside
measurement range" parameter must be activated.
Parameter Description Value range Default Unit CR
Scaling fac-
tor in [‰]
Scaling factor used to convert
the position values.
0…65,535 1,000 ‰–
Parameter Description Value range Default Unit CR
Offset value
in [mm]
Offset value added to tape
value.
-10,000,000 … 10,000,000 0 mm –
Parameter Description Value range Default Unit CR
Min. mea-
surement
length in
[mm]
Minimum permitted mea-
surement length.
0 … 2,147,483,647 0 mm
Switching out-
put
,
Max. mea-
surement
length in
[mm]
Maximum permitted mea-
surement length.
0 … 2,147,483,647 10,000,000 mm
Switching out-
put
,
