Configuration / device parameters
Leuze electronic BPS 8 81
TNT 35/7-24V
Parameters
The switching input function Pos. measurement start/stop in the Function parameter
means:
• High level at the switching input starts the position measurement.
• Low level at the switching input stops the position measurement.
Parameter Description Value range Default Unit CR
Digital
I/O mode
Defines whether the switching
input and output are activated
via the MA 8-01/MA 8-02 or
whether only the switching input
or only the switching output is
activated.
0: Not released
1: BPS 8 with MA 8-01/
MA 8-02 (switching
input + switching
output)
2: Switching input
3: Switching output
1 ––
Inversion
The parameter defines the logic
of the applied signal. In case of
an inversion, an external HIGH
level is interpreted as an inter-
nal LOW level.
0: No (active high)
1: Yes (active low)
0 ––
Mode
This parameter controls the
release of the switching input.
0: Off
1: On
1 ––
Debounce
time in [ms]
This parameter defines a
debounce time which is imple-
mented via software.
0…255 5 ms –
Start-up
delay in
[ms]
The parameter influences the
timing during switch-on.
0 … 65535 0 ms –
Pulse dura-
tion in [ms]
The parameter defines a mini-
mum time period before the sig-
nal is reset.
0 … 65535 0 ms –
Switch-off
delay in
[ms]
The parameter defines a time
delay for the signal during
switch-off.
0 … 65535 0 ms –
Function
The parameter specifies the
function which is to be activated
or deactivated by a status
change at the switching input.
0: No function
2 –
–
1: Teach preset
Position
detection
2: Start/stop position
measurement
Control
3: Stop position mea-
surement
Control
