Configuration / device parameters
Leuze electronic BPS 8 83
TNT 35/7-24V
Parameters
The events of the switch-on function and switch-off function are both linked to one another
with a logical OR.
Parameter Description Value range Default Unit CR
Digital
I/O mode
Defines whether the switching
input and output are activated
via the MA 8-01/MA 8-02 or
whether only the switching input
or only the switching output is
activated.
0: Not released
1: BPS 8 with MA 8-01/
MA 8-02 (switching
input + switching
output)
2: Switching input
3: Switching output
1 ––
Bias level /
inverted
The parameter defines the bias
level of the switching output.
0: LOW (0V)
1: HIGH (+Ub)
0 ––
Pulse dura-
tion in [ms]
The parameter defines the
switch-on time period for the
switching output. If the value is
0, the signal is static.
0 ... 1300 400 ms –
Switch-on
function
[EF]
The parameter specifies the
events which set the switching
output:
Each
0: Not active
1: Active
–
- outside measurement range 0
Position
detection
,
- within measurement range 0
Position
detection
,
- erroneous measurement 1
Position
detection
- successful measurement 0
Position
detection
Switch-off
function
[AF]
The parameter specifies the
events which reset the switching
output:
Each
0: Not active
1: Active
–
–
- outside measurement range 0
Position
detection
,
- within measurement range 0
Position
detection
,
- erroneous measurement 0
Position
detection
- successful measurement 1
Position
detection
a
b
c
d
i
j
i
j
e
i
j
i
j
