Leviton omnilte - Figure 7 - Console Connections

Page 13
MENUCANCEL
MESSAGE
TEMP
EVENTS
ALL
SETUP
AUX
STATUS
FIRE

SECURITYCONTROL BUTTONS
POL
(MOUNTED TO CONSOLE FACE)
CONSOLE PC BOARD
BOTTOM PLATE
YELLOW
GREEN
RED
BLACK
CONNECT ENDS OF SUPPLIED
CABLE TO CORRESPONDING
ENDS OF 4 - WIRE CABLE
FROM CONTROLLER
SUPPLIED CABLE
(PLUGS INTO J1)
GREEN YELLOW
BLACK RED
(SNAPS ON TO BOTTOM PLATE)
CONSOLE FACE
FOR MODEL NUMBERS
SEE NOTE 1 UNDER
"LCD CONSOLE HOOKUP"
FIGURE 7 - CONSOLE CONNECTIONS
