4511-xxx
3-20 Service Manual
PRINTER SETUP
Defaults See “Defaults” on page 3-29.
Page Count See “Page Count” on page 3-29.
Perm Page Count See “Perm Page Count (permanent page
count)” on page 3-29.
Serial Number See “Serial Number” on page 3-30.
Engine Setting 1
through 4
See “Engine Setting 1 through 4” on
page 3-30.
Model Name See “Model Name” on page 3-30.
Configuration ID See “Configuration ID” on page 3-30.
Edge to Edge See “Edge to Edge” on page 3-30.
Par S Strobe Adj See “Parallel strobe adjustment (Par S
Strobe Adj)” on page 3-30.
EP SETUP
EP Defaults See “EP Defaults” on page 3-31.
Fuser Temp See “Fuser Temperature (Fuser Temp)” on
page 3-31.
Transfer See “Transfer” on page 3-31.
Print Contrast See “Print Contrast” on page 3-31.
Charge Roll See “Charge Roll” on page 3-31.
Gap Adjust See “Gap Adjust” on page 3-31.
ERROR LOG
Display Log See “Display Log” on page 3-32.
Print Log See “Print Log” on page 3-33.
Clear Log See “Clear Log” on page 3-33.
EXIT DIAGNOSTICS
Diagnostics mode tests (continued)
To Next Page
