4511-xxx
3-22 Service Manual
Quick Test
The Quick Test contains the following information:
• Print registration settings
• Alignment diamonds at the top and bottom
• Horizontal lines to check for skew
• General printer information, including current page count, installed
memory, serial number, and code level.
To print the Quick Test page:
Note: Print the Quick Test Page on letter or A4 paper.
1. Select REGISTRATION from DIAGNOSTICS.
2. Press Go.
Once the Quick Test Page completes printing, the Registration screen
displays again.
Print tests
Input source tests
Input source print tests can verify that the printer can print on media from
the installed input sources. Only installed sources appear in the menu.
To run the input source test:
1. Select PRINT TESTS from Diagnostics Mode.
2. Select the input source from the sources displayed on the Feed Test
menu. All installed sources are listed.
3. Select either Single (feeds one sheet of blank media from the selected
source) or Continuous (continues feeding blank media from the
selected source until Return or Stop is pressed).
Press Return or Stop to exit the test.
Menu selections Description
Tray 1 Standard tray
Tray 2* Optional tray
* If installed
