Parts catalog
7-1
7. Parts catalog
How to use this parts catalog
The following legend is used in the parts catalog:
• Asm-index: identifies the assembly and the item in the diagram. For
example 3-1 indicates assembly 3 and the item number 1.
• Part number: identifies the unique number that identifies this FRU.
• Units/mach: refers to the number of units actually used in the machine
or product.
• Units/FRU: refers to the number of units packaged together and
identified by the part number.
• NS: (Not shown) in the Asm-Index column indicates that the part is
procurable but is not pictured in the illustration.
• PP: (Parts Packet) in the parts description column indicates the part is
contained in a parts packet.
• Model information used in the parts catalog.
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
Machine type
and model
Description
4511-000 Lexmark E238
4511-100 Lexmark E240
4511-410 Lexmark E240n (network)
4511-600 Lexmark E340
4511-610 Lexmark E342n (network)
