Lexmark E240n

4511-xxx
4-30 Service Manual
Fuser idle gear links removal
1. Remove the front access cover. For models E238, E240, and E240n,
see “Front access cover removal (E238, E240, and E240n)” on
page 4-2.
For models E340 and E342n, first perform steps 1 and 2 of “Front
access cover removal (E340 and E342n)” on page 4-5. Gently pull
enough slack in the cable to remove the cover without disconnecting
the cable, then follow the instructions for E238, E240, and E240n
models.
2. Remove the left side cover. See “Left side cover removal” on
page 4-9.
3. Place printer on its right side. Protect the cover from being marred.
4. Remove the screws (A) securing the metal plate covering the gear
train.
A
