Lexmark E240n

4511-xxx
4-14 Service Manual
Top cover removal
1. Open the front access cover.
2. Open the left cover.
3. Open the right cover.
4. Open the rear door.
5. Remove two screws (A) at the top rear corners of the top cover.
6. Remove two screws (B) at the front of the top cover just behind the
access door.
7. Release the top cover latch (C) which holds the top cover to the metal
side frame.
8. Lift and remove the top cover.
A BBC
