4511-xxx
4-38 Service Manual
4. If the bezel will be reused, stick a piece of tape (B) across the LCD lens
and bezel.
Use about three inches of tape and fold the end under to form a tab to
allow easy removal after reinstallation.
5. Using your fingernail or sharp, non-marring object, pull the top of the
bezel away from the front access cover. Carefully work the bezel away
from the buttons and front access cover.
Note: Push down on the top edge of the bezel to deflect it away from
the buttons. If the bezel does not easily come out, open the front
access cover, remove the three screws holding the shield cover
behind the LCD panel, and release the bezel latch.
B
To Next Page
