Lexmark E240n

4511-xxx
Locations and connections
5-5
J8 1 – +3.3 V dc Ready mode, main motor
drive.
2–+3.3Vdc
3–+3.3Vdc
4–+3.3Vdc
5 Ground Ground
6+5Vdc+5Vdc
7, 8, 9 +24 V dc <+24 V dc
J9 1 +1.1 V dc +5 V dc Input sensor, Ready
mode
2+5Vdc+5Vdc
3 Ground Ground
J10 1, 2 Signal Signal Smart chip
J11 1 Signal Signal Toner low sensor
2 Ground Ground
3 Signal Signal
J13 1 Mirror motor, Ready
mode
2, 3 +5 V dc +5 V dc
4 Ground Ground
5 +24 V dc +24 V dc
J14 1 – LSU, Ready mode
2 Ground Ground
3 +3.3 V dc –
4 Signal –
5 +3.3 V dc –
6 Ground Ground
7+5Vdc+5Vdc
8 Ground Ground
9+5Vdc –
J15 1 +5 V dc 0 V dc Door open sensor,
Ready mode (door
closed)
2+5Vdc+5Vdc
3 Ground Ground
Connector Pin #
Value
(plugged)
Value
(unplugged) Comments
